Full Trough Element (IFTE)

ftel-2

Full Trough Elements are a curved ceramic element 245×60mm with mounting neck behind the emitter. Available in wattages from 150W to 1000W with or without a thermocouple.K Type thermocouple is available as a standard. We can also supply these with a J Type thermocouple, and can have them pre-calibrated prior to being shipped from Ireland.

Part No.
Description
Dimensions
Wattage
Voltage
T’Couple
IFTE150
Full Trough Emitter
245 × 60 x 31mm
150W
240V
N/A
IFTE150T
Full Trough Emitter
245 × 60 x 31mm
150W
240V
Std K Type
IFTE250
Full Trough Emitter
245 × 60 x 31mm
250W
240V
N/Al
IFTE250T
Full Trough Emitter
245 × 60 x 31mm
250W
240V
Std K Type
IFTE300
Full Trough Emitter
245 × 60 x 31mm
300W
240V
N/A
IFTE300T
Full Trough Emitter
245 × 60 x 31mm
300W
240V
Std K Type
IFTE400
Full Trough Emitter
245 × 60 x 31mm
400W
240V
N/A
IFTE400T
Full Trough Emitter
245 × 60 x 31mm
400W
240V
Std K Type
IFTE500
Full Trough Emitter
245 × 60 x 31mm
500W
240V
N/A
IFTE500T
Full Trough Emitter
245 × 60 x 31mm
500W
240V
Std K Type
IFTE650
Full Trough Emitter
245 × 60 x 31mm
650W
240V
N/A
IFTE650T
Full Trough Emitter
245 × 60 x 31mm
650W
240V
Std K Type
IFTE750
Full Trough Emitter
245 × 60 x 31mm
750W
240V
N/A
IFTE750T
Full Trough Emitter
245 × 60 x 31mm
750W
240V
Std K Type
IFTE1000
Full Trough Emitter
245 × 60 x 31mm
1000W
240V
N/A
IFTE1000T
Full Trough Emitter
245 × 60 x 31mm
1000W
240V
Std K Type

Large Full Trough Element (ILFTE)

lfte-2

This is a larger element than the more commonly used FTE element.

It is 245×110mm long and available in 1000W and 1500W.

Part No. Description Dimensions Wattage Voltage T’Couple
ILFTE1000
Large Full Trough Element
245 x 110 x 37mm
1000W
240V
N/A
ILFTE1000T
Large Full Trough Element
245 × 110 x 37mm
1000W
240V
Std K Type
ILFTE1500
Large Full Trough Element
245 × 110 x 37mm
1500W
240V
N/A
ILFTE1500T
Large Full Trough Element
245 × 110 x 37mm
1500W
240V
Std K Type

Half Trough Element (IHTE)

hte

The IHTE is similar to the Full Trough Element, but half as long at 122×60mm. Available in wattages from 125W to 500W.

Part No. Description Dimensions Wattage Voltage T’Couple
IHTE125
Half Trough Element
122 × 60 x 31mm
125W
240V
N/A
IHTE125T
Half Trough Element
122 × 60 x 31mm
125W
240V
Std K Type
IHTE150
Half Trough Element
122 × 60 x 31mm
150W
240V
N/A
IHTE150T
Half Trough Element
122 × 60 x 31mm
150W
240V
Std K Type
IHTE200
Half Trough Element
122 × 60 x 31mm
200W
240V
N/A
IHTE200T
Half Trough Element
122 × 60 x 31mm
200W
240V
Std K Type
IHTE250
Half Trough Element
122 × 60 x 31mm
250W
240V
N/A
IHTE250T
Half Trough Element
122 × 60 x 31mm
250W
240V
Std K Type
IHTE325
Half Trough Element
122 × 60 x 31mm
325W
240V
N/A
IHTE325T
Half Trough Element
122 × 60 x 31mm
325W
240V
Std K Type
IHTE500
Half Trough Element
122 × 60 x 31mm
500W
240V
N/A
IHTE500T
Half Trough Element
122 × 60 x 31mm
500W
240V
Std K Type

Quarter Trough Element (IQTE)

qte

Whereas the IQTE is smaller again at 61×60mm, available in wattages of 125W & 250W.

Part No. Description Dimensions Wattage Voltage T’Couple
IQTE125
Quarter Curved Element
60 × 60 x31mm
125W
240V
N/A
IQTE125T
Quarter Curved Element
60 x 60 x 31mm
125W
240V
Std K Type
IQTE250
Quarter Curved Element
60 x 60 x 31mm
250W
240V
N/A
IQTE250T
Quarter Curved Element
60 x 60 x 31mm
250W
240V
Std K Type

Quarter Curve Element (IQCE)

qce

A 61×60mm element with a more distinct curve, the distance from the front of the emitter to the back of the mounting neck is 41mm instead of the standard 31mm. Available in wattages of 125W & 250W.

Part No. Description Dimensions Wattage Voltage T’Couple
IQCE150
Quarter Curved Element
60 × 60 x 40mm
150W
240V
N/A
IQCE150T
Quarter Curved Element
60 x 60 x 40mm
150W
240v
Std K Type
IQCE250
Quarter Curved Element
60 x 60 x 40mm
250W
240V
N/A
IQCE250T
Quarter Curved Element
60 x 60 x 40mm
250W
240V
Std K Type

Edison Screw Element (IESE)

ceramic-bulbs

These elements are made in a bulb shape are predominantly used for animal husbandry.

These ceramic bulbs have a standard Edison Screw base (27mm).

They are available in 60W-500W in various sizes.

The following table show the different sizes available:

Part No. Description Dimensions Wattage Voltage T’Couple
IESE-060
E.S.E. Ceramic Bulb
80×110mm
60W
240V
N/A
IESE-100
E.S.E. Ceramic Bulb
80×110mm
100W
240V
N/A
IESE-150
E.S.E. Ceramic Bulb
95×140mm
150W
240V
N/A
IESE-250
E.S.E. Ceramic Bulb
95×140mm
250W
240V
N/A
IESE-500
E.S.E. Ceramic Bulb
140×140mm
500W
240V
N/A

Full Flat Element (IFFE)

ftel-2

The IFFE is the same dimensions as the IFTE element (245x60mm), however the face of the element is not curved, therefore its mounting profile is slightly less than the IFTE at 24mm.

Available in same wattages as the IFTE element, from 150W to 1000W, with or without a thermocouple.

Part No. Description Dimensions Wattage Voltage T’Couple
IFFE150
Full Flat Element
245 × 60 x 24mm
150W
240V
N/A
IFFE150T
Full Flat Element
245 × 60 x 24mm
150W
240V
Std K Type
IFFE250
Full Flat Element
245 × 60 x 24mm
250W
240V
N/A
IFFE250T
Full Flat Element
245 × 60 x 24mm
250W
240V
Std K Type
IFFE300
Full Flat Element
245 × 60 x 24mm
300W
240V
N/A
IFFE300T
Full Flat Element
245 × 60 x 24mm
300W
240V
Std K Type
IFFE400
Full Flat Element
245 × 60 x 24mm
400W
240V
N/A
IFFE400T
Full Flat Element
245 × 60 x 24mm
400W
240V
Std K Type
IFFE500
Full Flat Element
245 × 60 x 24mm
500W
240V
N/A
IFFE500T
Full Flat Element
245 × 60 x 24mm
500W
240V
Std K Type
IFFE650
Full Flat Element
245 × 60 x 24mm
650W
240V
N/A
IFFE650T
Full Flat Element
245 × 60 x 24mm
650W
240V
Std K Type
IFFE750
Full Flat Element
245 × 60 x 24mm
750W
240V
N/A
IFFE750T
Full Flat Element
245 × 60 x 24mm
750W
240V
Std K Type
IFFE1000
Full Flat Element
245 × 60 x 24mm
1000W
240V
N/A
IFFE1000T
Full Flat Element
245 × 60 x 24mm
1000W
240V
Std K Type

Large Full Flat Element (ILFFE)

lffe

The emitter is similar to the IFFE.

With dimensions of 245×95mm, it is available in 150W-1400W. Can be supplied with standard K or specially ordered J type thermocouples.

Part No. Description Dimensions Wattage Voltage T’Couple
ILFFE150
Large Full Flat Element
245 × 95 x 24mm
150W
240V
N/A
ILFFE150T
Large Full Flat Element
245 × 95 x 24mm
150W
240V
Std K Type
ILFFE350
Large Full Flat Element
245 × 95 x 24mm
350W
240V
N/A
ILFFE350T
Large Full Flat Element
245 × 95 x 24mm
350W
240V
Std K Type
ILFFE750
Large Full Flat Element
245 × 95 x 24mm
750W
240V
N/A
ILFFE750T
Large Full Flat Element
245 × 95 x 24mm
750W
240V
Std K Type
ILFFE1400
Large Full Flat Element
245 × 95 x 24mm
1400W
240V
N/A
ILFFE1400T
Large Full Flat Element
245 × 95 x 24mm
1400W
240V
Std K Type

Half Flat Element (IHFE)

hfe-2

The IHFE is similar to the Full Flat Element, but half as long at 122×60mm.

Available in wattages from 125W to 500W.

Part No. Description Dimensions Wattage Voltage T’Couple
IHFE125
Half Flat Element
122 x 60 x 24mm
125W
240V
N/A
IHFE125T
Half Flat Element
122 × 60 x 24mm
125W
240V
Std K Type
IHFE150
Half Flat Element
122 × 60 x 24mm
150W
240V
N/A
IHFE150T
Half Flat Element
122 × 60 x 24mm
150W
240V
Std K Type
IHFE200
Half Flat Element
122 × 60 x 24mm
200W
240V
N/A
IHFE200T
Half Flat Element
122 × 60 x 24mm
200W
240V
Std K Type
IHFE250
Half Flat Element
122 × 60 x 24mm
250W
240V
N/A
IHFE250T
Half Flat Element
122 × 60 x 24mm
250W
240V
Std K Type
IHFE325
Half Flat Element
122 × 60 x 24mm
325W
240V
N/A
IHFE325T
Half Flat Element
122 × 60 x 24mm
325W
240V
Std K Type
IHFE500
Half Flat Element
122 × 60 x 24mm
500W
240V
N/A
IHFE500T
Half Flat Element
122 × 60 x 24mm
500W
240V
Std K Type

Quarter Flat Element (IQFE)

qfe

Whereas the IQFE is smaller again at 60×60mm, available in wattages of 125W & 250W.

Part No. Description Dimensions Wattage Voltage T’Couple
IQFE125
Quarter Flat Element
60×60 x 24mm
125W
240V
N/A
IQFE125T
Quarter Flat Element
60 × 60 x 24mm
125W
240V
Std K Type
IQFE250
Quarter Flat Element
60 × 60 x 24mm
250W
240V
N/A
IQFE250T
Quarter Flat Element
60 × 60 x 24mm
250W
240V
Std K Type

Square Flat Solid Element (ISFSE)

sfse

The emitter is as the part number suggests, a square flat element.

122×122m available in 150W-1000W.

K Type thermocouple is available as a standard. We can also supply these with a J Type thermocouple

Part No. Description Dimensions Wattage Voltage T’Couple
ISFSE150
Square Flat Solid Element
122 × 122 x 24mm
150W
240V
N/A
ISFSE150T
Square Flat Solid Element
122 × 122 x 24mm
150W
240V
K Type
ISFSE250
Square Flat Solid Element
122 × 122 x 24mm
250W
240V
N/A
ISFSE250T
Square Flat Solid Element
122 × 122 x 24mm
250W
240V
K Type
ISFSE300
Square Flat Solid Element
122 × 122 x 24mm
300W
240V
N/A
ISFSE300T
Square Flat Solid Element
122 × 122 x 24mm
300W
240V
K Type
ISFSE350
Square Flat Solid Element
122 × 122 x 24mm
350W
240V
N/A
ISFSE350T
Square Flat Solid Element
122 × 122 x 24mm
350W
240V
K Type
ISFSE400
Square Flat Solid Element
122 × 122 x 24mm
400W
240V
N/A
ISFSE400T
Square Flat Solid Element
122 × 122 x 24mm
400W
240V
K Type
ISFSE500
Square Flat Solid Element
122 × 122 x 24mm
500W
240V
N/A
ISFSE500T
Square Flat Solid Element
122 × 122 x 24mm
500W
240V
K Type
ISFSE650
Square Flat Solid Element
122 × 122 x 24mm
650W
240V
N/A
ISFSE650T
Square Flat Solid Element
122 × 122 x 24mm
650W
240V
K Type
ISFSE750
Square Flat Solid Element
122 × 122 x 24mm
750W
240V
N/A
ISFSE750T
Square Flat Solid Element
122 × 122 x 24mm
750W
240V
K Type

Full Flat Hollow Element (IFFEH)

ffeh-2
  • Iron-chrome aluminium resistance wire
  • Heater Voltage: 230 Volts standard (other voltages available on request)
  • Useful wavelength range: 2-10 microns
  • Average Operating Life: 5,000 – 10,000 hours
  • Recommended radiation distance from heater is 100 mm to 200 mm
    Please click here for installation details
  • Supplied with 100mm ceramic beaded power leads
Part No. Description Dimensions Wattage Voltage T’Couple
IFFEH250
Full Flat Hollow Element
245 × 60 x 36mm
250W
240V
N/A
IFFEH250T
Full Flat Hollow Elemen
245 × 60 x36mm
250W
240V
K Type
IFFEH300
Full Flat Hollow Elemen
245 × 60 x 36mm
300W
240V
N/A
IFFEH300T
Full Flat Hollow Elemen
245 × 60 x 36mm
300W
240V
K Type
IFFEH400
Full Flat Hollow Element
245 × 60 x 36mm
400W
240V
N/A
IFFEH400T
Full Flat Hollow Elemen
245 × 60 x 36mm
400W
240V
K Type
IFFEH500
Full Flat Hollow Elemen
245 × 60 x 36mm
500W
240V
N/A
IFFEH500T
Full Flat Hollow Elemen
245 × 60 x 36mm
500W
240V
K Type
IFFEH600
Full Flat Hollow Elemen
245 × 60 x 36mm
600W
240V
N/A
IFFEH600T
Full Flat Hollow Elemen
245 × 60 x 36mm
600W
240V
K Type
IFFEH800
Full Flat Hollow Elemen
245 × 60 x 36mm
800W
240V
N/A
IFFEH800T
Full Flat Hollow Elemen
245 × 60 x 36mm
800W
240V
K Type

Half Flat Hollow Element (IHFEH)

hfeh-2
  • Iron-chrome aluminium resistance wire
  • Heater Voltage: 230 Volts standard (other voltages available on request)
  • Useful wavelength range: 2-10 microns
  • Average Operating Life: 5,000 – 10,000 hours
  • Recommended radiation distance from heater is 100 mm to 200 mm.
    Please click here for installation details
  • Supplied with 100mm ceramic beaded power leads
Part No. Description Dimensions Wattage Voltage T’Couple
IHFEH125
Half Flat Hollow Element
122 × 60 x 36mm
125W
240V
N/A
IHFEH125T
Half Flat Hollow Element
122 x 60 x 36mm
125W
240V
K Type
IHFEH200
Half Flat Hollow Element
122 x 60 x 36mm
200W
240V
N/A
IHFEH200T
Half Flat Hollow Element
122 x 60 x 36mm
200W
240V
K Type
IHFEH250
Half Flat Hollow Element
122 x 60 x 36mm
250W
240V
N/A
IHFEH250T
Half Flat Hollow Element
122 x 60 x 36mm
250W
240V
K Type
IHFEH300
Half Flat Hollow Element
122 x 60 x 36mm
300W
240V
N/A
IHFEH300T
Half Flat Hollow Element
122 x 60 x 36mm
300W
240V
K Type
IHFEH400
Half Flat Hollow Element
122 x 60 x 36mm
400W
240V
N/A
IHFEH400T
Half Flat Hollow Element
122 x 60 x 36mm
400W
240V
K Type

Quarter Flat Hollow Element (IQFEH)

qfeh
  • Iron-chrome aluminium resistance wire
  • Heater Voltage: 230 Volts standard (other voltages available on request)
  • Useful wavelength range: 2-10 microns
  • Average Operating Life: 5,000 – 10,000 hours
  • Recommended radiation distance from heater is 100 mm to 200 mm
    Please click here for installation details
  • Supplied with 100mm ceramic beaded power leads
Part No. Description Dimensions Wattage Voltage T’Couple
IQFEH125
Quarter Flat Hollow Element
60 × 60 x 36mm
125W
240V
N/A
IQFEH125T
Quarter Flat Hollow Element
60 x 60 x 36mm
125W
240V
K Type
IQFEH200
Quarter Flat Hollow Element
60 x 60 x 36mm
200W
240V
N/A
IQFEH200T
Quarter Flat Hollow Element
60 x 60 x 36mm
200W
240V
K Type

Square Flat Hollow Element (ISFEH)

sfeh-2
  • Iron-chrome aluminium resistance wire
  • Heater Voltage: 230 Volts standard (other voltages available on request)
  • Useful wavelength range: 2-10 microns
  • Average Operating Life: 5,000 – 10,000 hours
  • Recommended radiation distance from heater is 100 mm to 200 mm
    Please click here for installation details
  • Supplied with 100mm ceramic beaded power leads
Part No. Description Dimensions Wattage Voltage T’Couple
ISFEH250
Square Flat Hollow Element
122 × 122 x 36mm
250W
240V
N/A
ISFEH250T
Square Flat Hollow Element
122 × 122 x 36mm
250W
240V
K type
ISFEH300
Square Flat Hollow Element
122 × 122 x 36mm
300W
240V
N/A
ISFEH300T
Square Flat Hollow Element
122 × 122 x 36mm
300W
240V
K type
ISFEH400
Square Flat Hollow Element
122 × 122 x 36mm
400W
240V
N/A
ISFEH400T
Square Flat Hollow Element
122 × 122 x 36mm
400W
240V
K type
ISFEH500
Square Flat Hollow Element
122 × 122 x 36mm
500W
240V
N/A
ISFEH500T
Square Flat Hollow Element
122 × 122 x 36mm
500W
240V
K type
ISFEH600
Square Flat Hollow Element
122 × 122 x 36mm
600W
240V
N/A
ISFEH600T
Square Flat Hollow Element
122 × 122 x 36mm
600W
240V
K type
ISFEH800
Square Flat Hollow Element
122 × 122 x 36mm
800W
240V
N/A
ISFEH800T
Square Flat Hollow Element
122 × 122 x 36mm
800W
240V
K type

Quartz Elements

Quartz infrared heating Elements provide medium wave infrared radiation. They are favoured in industrial applications where rapid heater response is necessary, including systems with long heater off cycles.

  • Quartz infrared heating elements are particularly effective in systems where rapid heater response and/or zone controlled heating is required.
  • They have a broad emission spectrum and cover various absorption ranges.
  • Pillared quartz elements have the same mounting fixture as ceramic elements allowing replacement without difficulty.
  • This is ideal for design alternation involving the use of materials with different absorption characteristics.

Full Quartz Element

quartz-element-fqeFQE Standard Features

  • Iron-chrome aluminium resistance wire
  • Heater Voltage: 230 Volts standard (other voltages available on request)
  • Useful wavelength range: 1.5 – 8 microns
  • Recommended radiation distance from heater is 100 mm to 200 mm
    Please click here for installation details
  • Supplied with 100mm ceramic beaded power leads
Part No. Description Dimensions Wattage Voltage T’Couple
IFQE150
Full Quartz Element
247 x 62.5 x 22mm
150W
230V
N/A
IFQE250
Full Quartz Element
247 x 62.5 x 22mm
250W
230V
N/A
IFQE400
Full Quartz Element
247 x 62.5 x 22mm
400W
230V
N/A
IFQE500
Full Quartz Element
247 x 62.5 x 22mm
500W
230V
N/A
IFQE650
Full Quartz Element
247 x 62.5 x 22mm
650W
230V
N/A
IFQE750
Full Quartz Element
247 x 62.5 x 22mm
750W
230V
N/A
IFQE1000
Full Quartz Element
247 x 62.5 x 22mm
1000W
230V
N/A

Half Quartz Element (IHQE)

quartz-element-hqeHQE Standard Features

  • Iron-chrome aluminium resistance wire
  • Heater Voltage: 230 Volts standard (other voltages available on request)
  • Useful wavelength range: 1.5 – 8 microns
  • Recommended radiation distance from heater is 100 mm to 200 mm
    Please click here for installation details
  • Supplied with 100mm ceramic beaded power leads
Part No. Description Dimensions Wattage Voltage T’Couple
IHQE150
Half Quartz Element
124 x 62.5 x 22mm
150W
230V
N/A
IHQE250
Half Quartz Element
124 x 62.5 x 22mm
250W
230V
N/A
IHQE400
Half Quartz Element
124 x 62.5 x 22mm
400W
230V
N/A
IHQE500
Half Quartz Element
124 x 62.5 x 22mm
500W
230V
N/A

Quarter Quartz Element

quartz-element-qqeQQE Standard Features

  • Iron-chrome aluminium resistance wire
  • Heater Voltage: 230 Volts standard (other voltages available on request)
  • Useful wavelength range: 1.5 – 8 microns
  • Recommended radiation distance from heater is 100 mm to 200 mm
    Please click here for installation details
  • Supplied with 100mm ceramic beaded power leads
Part No. Description Dimensions Wattage Voltage T’Couple
IQQE150
Half Quartz Element
124 x 62.5 x 22mm
150W
230V
N/A
IQQE250
Half Quartz Element
124 x 62.5 x 22mm
250W
230V
N/A

Square Quartz Element (ISQE)

quartz-element-sqeSQE Standard Features

  • Iron-chrome aluminium resistance wire
  • Heater Voltage: 230 Volts standard (other voltages available on request)
  • Useful wavelength range: 1.5 – 8 microns
  • Recommended radiation distance from heater is 100 mm to 200 mm
    Please click here for installation details
  • Supplied with 100mm ceramic beaded power leads
Part No. Description Dimensions Wattage Voltage T’Couple
ISQE150
Square Quartz Element
124 x 124 x 22mm
150W
230V
N/A
ISQE250
Square Quartz Element
124 x 124 x 22mm
250W
230V
N/A
ISQE400
Square Quartz Element
124 x 124 x 22mm
400W
230V
N/A
ISQE500
Square Quartz Element
124 x 124 x 22mm
500W
230V
N/A
ISQE650
Square Quartz Element
124 x 124 x 22mm
650W
230V
N/A
ISQE750
Square Quartz Element
124 x 124 x 22mm
750W
230V
N/A
ISQE1000
Square Quartz Element
124 x 124 x 22mm
1000W
230V
N/A

Single Tube Quartz Heater (ISTQH)

quartz-tubes-stqhSTQH Standard Features

  • Iron-chrome aluminium resistance wire.
  • Heater Voltage: 230 Volts standard. (other voltages available on request)
  • Useful wavelength range: 1.5 – 8 microns.
  • Recommended radiation distance from heater is 100 mm to 200 mm.
  • Supplied with 100mm ceramic beaded power leads.
Size Description Wattage Range Voltage Drawings
100 x 100mm
Single Tube Quartz Heater
150-400W
230V
112 x 112mm
Single Tube Quartz Heater
150-400W
230V
140 x 140mm
Single Tube Quartz Heater
150-650W
230V
150 x 150mm
Single Tube Quartz Heater
150-650w
230V

Pillared Full Quartz Element (IPFQE)

quartz-element-pfqePFQE Standard Features

  • Iron-chrome aluminium resistance wire
  • Heater Voltage: 230 Volts standard (other voltages available on request)
  • Useful wavelength range: 1.5 – 8 microns
  • Recommended radiation distance from heater is 100 mm to 200 mm
    Please click here for installation details
  • Supplied with our 2 piece wave spring and clip.
Part No. Description Dimensions Wattage Voltage T’Couple
IPFQE150
Pillared Full Quartz Element
247 x 62.5 x 22mm
150W
230V
N/A
IPFQE250
Pillared Full Quartz Element
247 x 62.5 x 22mm
250W
230V
N/A
IPFQE400
Pillared Full Quartz Element
247 x 62.5 x 22mm
400W
230V
N/A
IPFQE500
Pillared Full Quartz Element
247 x 62.5 x 22mm
500W
230V
N/A
IPFQE650
Pillared Full Quartz Element
247 x 62.5 x 22mm
650W
230V
N/A
IPFQE750
Pillared Full Quartz Element
247 x 62.5 x 22mm
750W
230V
N/A
IPFQE1000
Pillared Full Quartz Element
247 x 62.5 x 22mm
1000W
230V
N/A

Pillared Half Quartz Element (IPHQE)

quartz-element-phqePHQE Standard Features

  • Iron-chrome aluminium resistance wire
  • Heater Voltage: 230 Volts standard (other voltages available on request)
  • Useful wavelength range: 1.5 – 8 microns
  • Recommended radiation distance from heater is 100 mm to 200 mm
    Please click here for installation details
  • Supplied with our 2 piece wave spring and clip.
Part No. Description Dimensions Wattage Voltage T’Couple
IPHQE150
Pillared Half Quartz Element
124 x 62.5 x 22mm
150W
230V
N/A
IPHQE250
Pillared Half Quartz Element
124 x 62.5 x 22mm
250W
230V
N/A
IPHQE400
Pillared Half Quartz Element
124 x 62.5 x 22mm
400W
230V
N/A
IPHQE500
Pillared Half Quartz Element
124 x 62.5 x 22mm
500W
230V
N/A

Projectors

projector-pas2-2Designed to cater for a wide range of Ceramic and Quartz Elements, the aluminised steel projectors are the ideal solution in areas where positional heat is required quickly, economically and effectively.

The P.A.S. can be fixed directly to walls and angled to give the most effective coverage of the area to be heated. They are very effective in areas where doors are continuously being opened or insulation is poor.

Part No. Description Dimensions(mm) Max Wattage Technical Information
H D L
IPAS-1 Aluminised Steel Projector 94 76 258 650W Tech. Sheet
IPAS-2 Aluminised Steel Projector 94 76 508 1300W Tech. Sheet
IPAS-3 Aluminised Steel Projector 94 76 758 1950W Tech. Sheet
IPAS-4 Aluminised Steel Projector 94 76 1008 2600W Tech. Sheet
IPAS-5 Aluminised Steel Projector 94 76 1258 3250W Tech. Sheet

Reflectors

reflector-ras-5Designed to cater for a wide range of Ceramic and Quartz Emitters, this aluminised steel reflector features a highly reflective casing, to maximise heat output. The units can be mounted individually or side-by-side to form IR panels.

The R.A.S. can efficiently heat a defined area within a large space or can totally heat either large or small areas alike.

Part No. Description Dimensions(mm) Max Wattage Technical Information
H D L
IRAS-1 Aluminised Steel Reflector 100 60 264 1000W Tech. Sheet
IRAS-2 Aluminised Steel Reflector 100 60 504 2000W Tech. Sheet
IRAS-3 Aluminised Steel Reflector 100 60 754 3000W Tech. Sheet
IRAS-4 Aluminised Steel Reflector 100 60 1004 4000W Tech. Sheet
IRAS-5 Aluminised Steel Reflector 100 60 1254 5000W Tech. Sheet

Ceramicx Spares

Image Part No. Description
ICTB2M 2 Way Terminal Block
ICTB3M 3 Way terminal block
IFCBH Flat Ceramic Base Holder
ICBR Ceramic Bulb Reflector
IBEADS Ceramic Beads Loose
IBEADS-S Ceramic Beads Strung
IE27B E27 Edison Screw Bulb Holder
IMB Mounting Bracket
ISSBB Stainless Steel Buzz Bars
ISTQHHOLDER STQH Holder
IVclip V-Clip
ISWSC Steel Wave Spring and Clip Set

Terminal Blocks

Image Partnumber Description
ICTB1MC Ceramic Terminal Block 1Way (6A) Brass Fittings
ICTB1B Ceramic Terminal Block 1 Way Closed Type with Fittings
ICTB2B Ceramic Terminal Block 2Way (30A) Brass Fittings
ICTB2BE Ceramic Terminal Block 2Way (30A) Brass Fittings
ICTB2MC Ceramic Terminal Block 2Way Closed type with fittings
ICTB3B Ceramic Terminal Block 3Way (30A) Brass Fittings
136/12 Plastic Terminal Strip, 12 Way, 10Amp
137/12 Plastic Terminal Strip, 12 Way, 25Amp
138/12 Plastic Terminal Strip, 12 Way, 50-70Amp
